SpeedyBee TX ULTRA 5,8 GHz 1600 mW 1,6 W 48-Kanal-VTX-Videosender

5.0

Verkäufe：20Stück

$44.99

~~$72.99~~

-38%

Gutschein verfügbar

● Adjustable Power Output and High-efficiency Heat Sink.

● IRC Tramp Protocol Support.

● Pit Mode Support.

● Side LED Indicators.

● Simple Installation.

Mehr erfahren

MEPSKING Neuheiten-Verkaufsevent: Mehr kaufen, mehr bekommen

Optionen (1)

SpeedyBee TX1600 Ultra VTX

Menge

Auf Lager Erwartete Lieferung Versand in 5 Tagen nach Bestellung.

Kostenloser Versand | Für Bestellungen über 99 $

2 Jahre Garantie | Sorglose 24-monatige Garantie

Einfache Rückgabe und Umtausch | Rückgabe innerhalb von 30 Tagen

Professioneller Support | 24-Stunden-Reaktion

Zahlung | Jede Bestellung, die Sie bei uns aufgeben, ist sicher & geschützt

Kopieren

Beschreibung

Bewertungen

FAQ

About SpeedyBee TX ULTRA FPV VTX:

The Speedybee TX1600 Ultra FPV VTX is a high-performance VTX designed to meet the demanding needs of serious FPV pilots. Featuring a compact 20x20mm mounting configuration, this FPV VTX delivers an impressive output power of up to 1600mW, making it an exceptional choice for long-range flights and environments requiring robust signal penetration. Built with precision and reliability in mind, the TX1600 Ultra FPV Video Transmitter stands out as a great option for pilots seeking unparalleled video transmission quality and performance in challenging conditions.

Features:

● Adjustable Power Output and High-efficiency Heat Sink: 5.8GHz 48CH PIT / 25mW / 200mW / 400mW / 800Mw switchable

● IRC Tramp Protocol Support : Support to modify the image transmitter parameters through the remote control.you can also modify the parameters of image transmitter through SpeedyBee App.

● Pit Mode Support : When you are flying in the same field with other players ,PitMode can make you more calm to power up the aircraft for parameter adjustment without disturbing other players,

● Side LED Indicators: 3 kind of color LED indicators help you know the intuitive status of the channel, band and the power.

● Simple Installation：Mounting hole distance of 20 * 20 mm makes convenient stacking with your other electronics.

Specifications:

● Model: SpeedyBee TX ULTRA

● Frequency & Channels: 5.8GHz, 48 Channels across 6 Bands

● Output Power: PIT / 25mW to 800mW / 1600mW (MAX)

● Operating Current: 12V @ 90~560mA

● Input Voltage: 7-28V (supports up to 6S)

● Output Voltage: 5V @ Maximum 300mA

● Video Input Impedance: 75 Ohm

● Antenna Connector Type: MMCX

● Weight: 3.2g without heatsink/antenna, 5.7g with heatsink, 7.0g with heatsink/antenna

● Dimensions: 29x28x6mm

● Mounting Holes: 20x20mm M2

Product recommendation:

● MEPS F7 flight controller

● MEPS 60A ESC

Package included:

● 1* SpeedyBee TX ULTRA VTX

SpeedyBee TX ULTRA with high performance

SpeedyBee TX ULTRA support IRC tramp protocol

SpeedyBee TX ULTRA with RX pairing function

Parameter

Gemfan 3520 3 Blade Propellers Specifications

Recommendations

SpeedyBee TX ULTRA recommend flight controller

Bewertungen (3)

S**********************************************************i

This VTX is simply amazing! The transmission quality is crystal clear, and the power output is strong and stable. I’ve tested it in different environments, and the signal holds up really well, even in areas with interference. The build quality is solid, and installation was a breeze. I got one for m
Model：SpeedyBee TX1600 Ultra VTX
B************n

The SpeedyBee TX Ultra is hands down one of the best VTXs I’ve used! The image clarity is top-notch, and I experienced zero signal dropouts. The adjustable power settings are a great feature, making it versatile for both long-range and indoor flying. I bought this to upgrade my old VTX.
Model：SpeedyBee TX1600 Ultra VTX
v******t

System default five-star praise
Model：SpeedyBee TX1600 Ultra VTX Zusätzliche Bewertungen nach 27 days
The VTX is very good and easy to install. It works nicely with SpeedyBee F405 V4. It takes a little space on the frame and would fit frames smaller than 5" (e.g. 3.5" or 2.5"). The product package includes the VTX, a mmcx2sma pig tail, a connector and an antenna.
